TREND ANALYSIS OF WINTER PRECIPITATION IN THE SUB-REGIONS OF HUNAN PROVINCE IN THE PAST 54 YEARS
-
摘要: 基于湖南省89个气象站点1960—2013年的冬季降水观测数据，应用旋转经验正交函数（REOF）和层次聚类法（HCA）对湖南省冬季降水进行分区，并在分区的基础上，运用离散小波变换结合Mann-Kendall（MK）和Sequential MK（SQMK）的方法，讨论湖南省各分区冬季降水的变化趋势，并识别影响各自变化趋势的主周期分量。结果表明：（1）REOF的前3个旋转空间模态揭示湖南省冬季降水存在3个主要的异常敏感区：湘南、湘西北及湘中；（2）湖南省冬季降水在空间上可划分为5个一致性子区域：湘西北区（DJF1）、湘西-湘北区（DJF2）、湘西南-湘中区（DJF3）、湘南丘陵区（DJF4）和湘南山地区（DJF5），且每一子区域从西南向东北呈带状展布；（3）近54年来，5个子区的冬季降水均表现出增加趋势但各区存在差异，其中，湘西南-湘中区、湘南丘陵区和湘南山地区均呈显著的上升趋势；（4）D1分量是影响湖南省不同区域冬季降水变化趋势的最占优的周期分量，揭示湖南省的冬季降水变化趋势存在准2年的主周期。Abstract: In this study, the hierarchical clustering analysis (HCA) coupled with rotated empirical orthogonal functions (REOF) is applied to form sub-regions based on the winter precipitation data of 89 meteorological stations in Hunan Province during the period 1960-2013. Then, the method, combined with discrete wavelet transform, Mann-Kendall (MK) and sequential MK (SQMK), is used to analyze the trend of precipitation change and identify the most dominant periodic components that affect winter precipitation trends in each sub-region. The results are as follows. (1) The first three rotated EOF modes reveal three principal precipitation anomaly sensitive areas in Hunan Province: south Hunan, northwest Hunan and central Hunan. (2) Winter precipitation in Hunan can be divided into five homogeneous and distinct regions: northwest Hunan (DJF1), west Hunan - north Hunan (DJF2), southwest Hunan - central Hunan (DJF3), hilly areas of south Hunan (DJF4), and mountain areas of south Hunan (DJF5). And each of sub-regions is extended belt-like from southwest to northeast. (3) In the past 54 years, winter precipitation has an increasing trend in each of five sub-regions, but these trends are different from each other. The southwest Hunan - central Hunan, hilly areas of south Hunan and mountainous areas of south Hunan exhibit a statistically significant upward trend. (4) The wavelet component D1 is the most effective periodic components affecting the winter precipitation trends in the different regions of Hunan Province. It suggests that 2-year periodic events are the main driver behind the observed trend of precipitation in Hunan Province.
-
Key words:
- winter precipitation /
- regionalization /
- trend analysis /
- Hunan Province
-
表 1 EOF和REOF前3个模态的方差贡献及累计方差贡献(%)
模态 EOF REOF 方差贡献 累积方差贡献 方差贡献 累积方差贡献 1 67.83 67.83 75.35 75.35 2 12.47 80.30 5.64 80.99 3 5.19 85.49 4.50 85.49
下载: 导出CSV
表 2 各分区的面积和区域平均冬季降水量
分区名称 气象站点数 区域面积/km2 面积百分比/% 区域平均冬季降水/mm DJF1 20 54265.05 25.05 134.03 DJF2 19 54871.94 25.33 173.18 DJF3 18 41310.85 19.07 197.93 DJF4 17 37104.75 17.13 205.47 DJF5 15 29075.57 13.42 208.24
下载: 导出CSV
表 3 各分区的最佳db小波类型和最优分解层
分区名称 最佳db类型 最优分解层 MRE er DJF1 db1 3 0.25 0.50 DJF2 db8 2 0.21 1.26 DJF3 db2 3 0.23 0.004 DJF4 db7 2 0.24 0.06 DJF5 db10 3 0.34 0.04
下载: 导出CSV
表 4 各分区单个分量和不同Dj+AJ分量与原始降水序列u(t)值间的RMSE和R以及各自的MK-Z值
Data DJF1 DJF2 DJF3 DJF4 DJF5 Z RMSE R Z RMSE R Z RMSE R Z RMSE R Z RMSE R original 0.75 - - 0.62 - - 2.21* - - 2.68* - - 2.65* - - D1 0.06 1.33 0.41* 0.44 0.70 0.57* 0.00 1.28 0.16 0.08 1.92 0.35* 0.03 2.09 0.27 D2 -0.04 1.41 0.26 -0.25 0.95 0.56* 0.46 1.07 0.42* 2.81* 1.65 0.41* 0.11 1.77 -0.54* D3 0.28 1.47 0.37* - - - 0.35 1.32 0.01 - - - -0.20 1.69 0.02 A2 - - - 1.40 2.47 0.68* - - - 2.84* 1.80 0.77* - - - A3 1.12 1.75 0.79* - - - 2.22* 2.82 0.79* - - - 2.54* 4.34 0.76* D1+A2 - - - 0.66 0.68 0.90* - - - 1.68 0.32 0.92* - - - D2+A2 - - - 1.00 0.92 0.94* - - - 2.37* 1.25 0.84* - - - D1+A3 0.85 0.60 0.83* - - - 2.42* 0.60 0.84* - - - 1.36 0.49 0.83* D2+A3 1.10 0.99 0.83* - - - 2.37* 1.35 0.87* - - - 1.90 2.49 0.80* D3+A3 1.59 1.25 0.92* - - - 2.87* 2.11 0.84* - - - 1.67 1.92 0.74* 注：加粗字体为最匹配原始序列变化趋势的Dj+AJ分量，带*的值均通过了0.05的显著性水平检验。
下载: 导出CSV
-
[1] IPCC.Climate Change 2013: The physical science basis contribution of working group one to the fifth assessment report of the intergovernmental panel on climate change[C].Cambridge: Cambridge University Press, 2013: 1-1 552. [2] 陆文秀, 刘丙军, 陈俊凡, 等.近50 a来珠江流域降水变化趋势分析[J].自然资源学报, 2014, 29(1):80-90. [3] 钱卓蕾.长江中下游冬季降水特征和影响因素分析[J].高原气象, 2013, 32(6):1 795-1 802. [4] NALLEY D, ADAMOWSKI J, KHALIL B.Using discrete wavelet transforms to analyze trends in streamflow and precipitation in Quebec and Ontario (1954-2008)[J].J Hydrol, 2012, 475(26):204-228. [5] PALIZDAN N, FALAMARZI Y, HUANG Y F, et al.Precipitation trend analysis using discrete wavelet transform at the Langat River Basin, Selangor, Malaysia[J].Stochastic Environmental Research & Risk Assessment, 2016:1-25. [6] CHEN Y Z, GUAN Y Q, SHAO G W, et al.Investigating trends in streamflow and precipitation in Huangfuchuan Basin with wavelet analysis and the Mann-Kendall test[J].Water, 2016, 8(3):77. [7] 王兵, 胡娅敏, 杜尧东, 等.小波分析和EEMD方法在广州气温及降水的多尺度分析中的差异分析[J].热带气象学报, 2014, 30(4):769-776. [8] 郑腾飞, 刘显通, 万齐林, 等.近50年广东省分级降水的时空分布特征及其变化趋势的研究[J].热带气象学报, 2017, 33(2):212-220. [9] 张永领, 高全洲, 丁裕国, 等.长江流域夏季降水的时空特征及演变趋势分析[J].热带气象学报, 2006, 22(2):161-168. [10] 吴林, 覃峥嵘, 黄大贞, 等.华南区域季节性降水的差异分析[J].气象研究与应用, 2009, 30(3):5-7. [11] 王兆礼, 陈晓宏, 张灵, 等.近40年来珠江流域降水量的时空演变特征[J].水文, 2006, 26(6):71-75. [12] 赵恩榕, 简茂球, 李春晖.华南降水季节演变的年代际变化[J].热带气象学报, 2018, 34(3):360-370. [13] 丁一汇.东亚冬季风的统计研究[J].热带气象学报, 1990, 6(2):119-128. [14] 王林, 冯娟.我国冬季降水年际变化的主模态分析[J].大气科学, 2011, 35(6):1 105-1 116. [15] 李天然, 张人禾, 温敏.ENSO对中国冬半年降水影响的不对称性及机制分析[J].热带气象学报, 2017, 33(1):1-10. [16] 简云韬, 简茂球, 杨崧.前、后冬的东亚冬季风年际变异及其与东亚降水的关系[J].热带气象学报, 2017, 33(4):502-529. [17] XU J, CHAN J C L.Interannual and interdecadal variability of winter precipitation over China in relation to global sea level pressure anomalies[J].Adv Atmos Sci, 2002, 19(5):914-926. [18] ZHOU L T.Impact of East Asian winter monsoon on rainfall over southeastern China and its dynamical process[J].Int J Climatol, 2011, 31(5):677-686. [19] 孙建奇, 敖娟.中国冬季降水和极端降水对变暖的响应[J].科学通报, 2013, 58(8):674-679. [20] 尚程鹏, 章新平, 张新主, 等.洞庭湖流域近54a来冬季降水及其异常环流特征分析[J].长江流域资源与环境, 2017, 26(8):1 284-1 294. [21] 徐晶, 林建, 姚学祥, 等.七大江河流域面雨量计算方法及应用[J].气象, 2001, 27(11):13-16. [22] 邓爱军, 陶诗言, 陈烈庭.我国汛期降水的EOF分析[J].大气科学, 1989, 13(3):289-295. [23] 熊光洁, 王式功, 尚可政, 等.中国西南地区近50年夏季降水的气候特征[J].兰州大学学报(自科版), 2012, 48(4):45-52. [24] HANNACHI A, JOLLIFFE I T, STEPHENSON D B.Empirical orthogonal functions and related techniques in atmospheric science:A review[J].Int J Climatol, 2007, 27(9):1 119-1 152. [25] ROUSSEEUW P J.Silhouettes:A graphical aid to the interpretation and validation of cluster analysis[J].Journal of Computational & Applied Mathematics, 1987, 20(20):53-65. [26] DOMROES M, KAVIANI M, SCHAEFER D.An Analysis of regional and intra-annual precipitation variability over Iran using multivariate statistical methods[J].Theoretical & Applied Climatology, 1998, 61(3-4):151-159. [27] RAZIEI T.A precipitation regionalization and regime for Iran based on multivariate analysis[J].Theoretical & Applied Climatology, 2017:1-20. [28] 向旬, 王冀, 王绪鑫, 等.我国极端气温指数的时空变化与分区研究[J].气象, 2008, 34(9):73-80. [29] NORTH G R, BELL T L, CAHALAN R F, et al.Sampling Errors in the Estimation of Empirical Orthogonal Functions[J].Mon Wea Rev, 1982, 110(7):699. [30] HE X G, GUAN H D.Multiresolution analysis of precipitation teleconnections with large-scale climate signals:A case study in South Australia[J].Water Resources Research, 2013, 49(10):6 995-7 008. [31] HAMED K H, RAO A R.A modified Mann-Kendall trend test for autocorrelated data[J].J Hydrol, 1998, 204(1-4):182-196. [32] 魏凤英.现代气候统计诊断与预测技术[M].北京:气象出版社, 2007. [33] 陈少勇, 郭凯忠, 吴芳蓉, 等.中国南方冬季降水异常的时空分布特征分析[J].气候变化研究快报, 2014, 03(4):165-175. [34] KAISER G.A friendly guide to wavelets[J].Proceeding of the IEEE, 1998, 86(11):2 387. [35] 张剑明, 黎祖贤, 章新平.1960-2005年湖南省降水的变化[J].气候变化研究进展, 2008, 4(2):101-105. -
点击查看大图
图(6) / 表(4)
