DAMAGE SURVEY, RADAR AND ENVIRONMENT ANALYSES OF A TYPHOON-INDUCED TORNADO IN SHANDONG
-
摘要: 2018年8月19日受台风“温比亚”影响，山东省临沂市遭受龙卷袭击。通过实地灾情调查，给出了该龙卷的影响范围、灾害分布和强度评估等，综合考虑不同标识物和致灾过程，评估本次龙卷强度为EF3级。分析龙卷发生的环境和天气雷达特征，结果表明：龙卷发生在低抬升凝结高度（≤300 m）、强低层垂直风切变（≥18×10-3 s-1）、强相对风暴螺旋度（≥350 m2/s2）和较低对流有效位能（≤400 J/kg）的有利环境条件下；龙卷超级单体嵌于台风右侧螺旋雨带内，龙卷发生在中气旋与风暴后侧下沉气流区相接一侧，与龙卷涡旋特征位置对应；龙卷及地时中气旋向下延伸加强，同时风暴顶及单体质心迅速下降；若探测到低层中等强度中气旋时应发布龙卷预警，则此次过程的龙卷预警时间提前量为15~20 min。Abstract: Affected by Typhoon Rumbia, Linyi was hit by a tornado on August 19, 2018. The damage swath and distribution, and intensity of the tornado are determined based on damage survey, and the tornado intensity is rated as EF3. Based on radar and environment analyses, following results are drawn. The tornado developed in a favorable environment where the low lifting condensation level was lower than 300 m, low-level vertical wind shear was above 18×10-3 s-1, storm relative helicity was above 350 m2/s2, and convective available potential energy was less than 400 J/kg. The tornado supercell was embedded in the spiral rainband on the right side of the typhoon. As the tornado appeared on the side where the mesocyclone was connected with the downdraft area on the back side of the storm, its position corresponded to the position of the tornadic vortex signature (TVS). The mesocyclone extended downward and strengthened when the tornado touched the ground; meanwhile, the top of the storm and the center of mass dropped rapidly. If tornado warning could be issued once the low-level medium-strength mesocyclone was detected, the warning lead time of this tornado would be about 15~20 minutes.
-
Key words:
- tornado /
- mesocyclone /
- TVS /
- wind speed assessment /
- EF scale
-
图 1 2018年8月19日汤头龙卷灾害调查评估综合图
红色实线为龙卷路径，蓝色标记为起点和终点，黑色框为调查区域（S1~S6），黑色箭头是实地调查中DI倒伏方向，蓝、紫、棕、黑色虚线分别为EF0、EF1、EF2、EF3区域。地图比例见左下角，圆圈内箭头方向为正北（下同）。
图 3 2018年8月19日19时500 hPa高度场（等值线，单位：dagpm）及风场（风矢，单位：m/s）（a），海平面气压场（等值线，单位：hPa）及风场（风矢，单位：m/s）（b）
-
[1] American Meteorological Society. Tornado[EB/OL]. (2020-11-2)[2021-02-26]. http://glossary.ametsoc.org/wiki/tornado. [2] EDWARDS R, LADUE J G, FERREE J T, et al. Tornado intensity estimation: past, present, and future[J]. Bull Amer Meteor Soc, 2013, 94 (5): 641-653. [3] ATKINS N T, BUTLER K M, FLYNN K R, et al. An integrated damage, visual, and radar analysis of the 2013 Moore, Oklahoma, EF5 Tornado[J]. Bull Amer Meteor Soc, 2014, 95(10): 1 549-1 561. [4] BURGESS D, ORTEGA K, STUMPF G, et al. 20 May 2013 Moore, Oklahoma, Tornado: damage survey and analysis[J]. Wea Forecasting, 2014, 29(5): 1 229-1 237. [5] 中国气象局. 中华人民共和国标准——龙卷风强度等级GB/T40243-2021[S]. 北京: 中国标准出版社. [6] MENG Z, YAO D. Damage survey, radar and environment analyses on the first-ever documented Tornado in Beijing during the heavy rainfall event of 21 July 2012[J]. Wea Forecasting, 2014, 29(3): 702-724 [7] MENG Z, YAO D, BAI L, et al. Wind estimation around the shipwreck of Oriental Star based on field damage surveys and radar observations[J]. Sci Bull, 2016, 61(4): 330-337 [8] 郑永光, 朱文剑, 姚聃, 等. 风速等级标准与2016年6月23日阜宁龙卷强度估计[J]. 气象, 2016, 42(11): 1 289-1 303. [9] 朱文剑, 盛杰, 郑永光, 等. 1522号台风"彩虹" 龙卷现场调查与中尺度特征分析[J]. 暴雨灾害, 2016, 35(5): 403-414. [10] BAI L, MENG Z,. HUANG L, et al.: An integrated damage, visual, and radar analysis of the 2015 Foshan, Guangdong EF3 Tornado in China produced by the landfalling Typhoon Mujigae (2015)[J]. Bull Amer Meteorl Soc, 2017, 98: 2 619-2 640. [11] 李兆慧, 王东海, 麦雪湖, 等 2015年10月4日佛山龙卷过程的观测分析[J]. 气象学报, 2017, 75(2): 288-313. [12] 刁秀广, 孟宪贵, 张立, 等. 台风"摩羯" 与"温比亚" 环流中龙卷小尺度涡旋特征及可预警性分析[J]. 海洋气象学报, 2019, 39(3): 19-28. [13] 赵海军, 潘玲, 曹张弛, 等. "温比亚" 引发3次龙卷的环境特征分析[J]. 热带气象学报, 2021, 37(5/6): 748-758. [14] 俞小鼎, 郑媛媛, 廖玉芳, 等. 一次伴随强烈龙卷的强降水超级单体风暴研究[J]. 大气科学, 2008, 32(3): 508-522. [15] 郑媛媛, 张备, 王啸华, 等. 台风龙卷的环境背景和雷达回波结构分析[J]. 气象, 2015, 41(8): 942-952. [16] 刁秀广, 万明波, 高留喜, 等. 非超级单体龙卷风暴多普勒天气雷达产品特征及预警[J]. 气象, 2014, 40(6): 668-677. [17] 周后福, 刁秀广, 夏文梅, 等. 江淮地区龙卷超级单体风暴及其环境参数分析[J]. 气象学报, 2014, 72(2): 306-317 [18] 张小玲, 杨波, 朱文剑, 等. 2016年6月23日江苏阜宁EF4级龙卷天气分析[J]. 气象, 2016, 42(11): 1 304-1 314. [19] 陈元昭, 俞小鼎, 陈训来, 等. 2015年5月华南一次龙卷过程观测分析[J]. 应用气象学报, 2016, 27(3): 334-341. [20] 郑艳, 俞小鼎, 任福民, 等. 海南一次超级单体引发的强烈龙卷过程观测分析[J]. 气象, 2017, 43(6): 675-685. [21] 赵海军, 刁秀广, 王庆华, 等. 非超级单体龙卷风暴低层流场特征及模拟分析[J]. 山东气象, 2016, 36(2): 1-8 [22] ZHAO K, WANG M, XUE M, et al. Doppler Radar analysis of a tornadic miniature supercell during the landfall of Typhoon Mujigae (2015) in South China[J]. Bull Amer Meteor Soc, 2017, 98(3): 1821-1831. [23] 范雯杰, 俞小鼎. 中国龙卷的时空分布特征[J]. 气象, 2015, 41(7) : 793-805. [24] 俞小鼎, 赵娟, 范雯杰. 中国龙卷的时空分布与关键环境参数特征[J]. 热带气象学报, 2021, 37 (5/6): 681-692. [25] 俞小鼎, 周小刚, 王秀明. 雷暴与强对流临近天气预报技术进展[J]. 气象学报, 2012, 70(3): 311-337. [26] 姚叶青, 郝莹, 张义军, 等. 安徽龙卷发生的环境条件和临近预警[J]. 高原气象, 2012, 31(6): 1 721-1 730. [27] 冯婧, 周伟灿, 徐影. 1980—2009年我国龙卷事件变化[J]. 气候变化研究进展, 2012, 8(3): 183-189. [28] 王秀明, 俞小鼎, 周小刚. 中国东北龙卷研究: 环境特征分析[J]. 气象学报, 2015, 73(3): 425-441. [29] XUE M, ZHAO K, WANG M J, et al. Recent significant tornadoes in China[J]. Adv Atmos Sci, 2016, 33(11): 1 209-1 217. [30] 王东海, 李兆慧, 高枞亭, 等. 中国与欧美龙卷统计特征比较分析及研究进展[J]. 气象科技进展, 2018, 8(2): 8-23. [31] 李彩玲, 谭浩波, 蔡康龙, 等. 2016—2020年中国龙卷过程和灾情特征[J]. 热带气象学报, 2021, 37(5/6): 733-747. [32] DOSWELL C A, BROOKS H E. Lessons learned from the damage produced by the tornadoes of 3 May 1999[J]. Wea Forecasting, 2002, 17 (3): 611-618. [33] ERIKN R. Refined Supercell and Tornado Forecast Parameters[J]. Wea Forecasting, 2003, 18(3): 530-535. [34] DAVIES-JONES R, BURGESS D, FOSTER M. Test of helicity as a tornado forecast parameter[C]. In: Preprints, 16th Conf on Severe Local Storms. Amer Meteor Soc, 1992. 588-592 [35] 俞小鼎, 姚秀萍, 熊廷南, 等. 多普勒天气雷达原理与业务应用[M]. 北京: 气象出版社, 2006: 130-143. -
