Identification and Evaluation Analysis of Wind Power Ramp Events—A Case Study of Shanxi Province
-
摘要: 基于2022年3月—2023年3月山西省全省风电场逐15 min风电总输出功率的实测和预测数据，对全省风电交易市场“功率预测曲线”进行误差分析，通过制定识别、匹配和评分方法，对风电爬坡事件的预报效果开展评估，进一步利用ERA5再分析资料对大范围风电爬坡现象发生的天气背景及演变开展分析。结果显示：（1）各季节早晨08时前后（北京时，下同）和夜间20时前后为每日预测误差最大的两个时段，同时两个时段误差离散度也相对较大，最大值可达4 000 MW。（2）弱爬坡事件的发生频率明显高于强爬坡事件，同时弱爬坡事件的预报技能得分（0.23）也高于强爬坡事件（0.05）。（3）风电爬坡事件主要发生在冬季和春季，每日08:00前后和19:00前后分别为下降爬坡事件和上升爬坡事件的集中发生时段，下午至前半夜以上升爬坡事件为主，后半夜至上午以下降爬坡事件为主。（4）当山西省位于地面高压后部或高空槽前时，地面高压的加深发展或槽前低空急流的建立会导致全省风电功率爬坡事件的发生。Abstract: Based on observation and forecast data of 15-min wind power output of all wind farms in Shanxi Province from March 2022 to March 2023, this study analyzed the errors of "power prediction curves" in the provincial wind power trading market. The forecasting effectiveness of wind power ramp events was evaluated by developing identification, matching, and scoring methods. The ERA5 reanalysis data were used to analyze the weather background and evolution of large-scale wind power ramp-up events. The results are shown as follows: (1) For all seasons, the periods around 08: 00 (Beijing Time, same below) and 20:00 are the two daily peaks of forecast error. Meanwhile, the error dispersion for the two periods is relatively large, with a maximum value of up to 4 000 MW. (2) The occurrence frequency for weak ramp events is significantly higher than strong ramp events. The forecasting skill score for weak ramp events is 0.23, which is higher than strong ramp events (0.05). (3) Wind power ramp events mainly occur in winter and spring. The periods around 8:00 and 19:00 each day are the concentrated occurrence times for ramp-down and ramp-up events, respectively. Ramp-up events mainly occur from afternoon to the first half of the night, while ramp-down events are dominant from the second half of the night to the next morning. (4) When Shanxi Province is located behind a high surface pressure or in front of an upper-air trough, the intensification of the surface high pressure or the establishment of a pre-trough low-level jet will lead to province-wide wind power ramp-up events.
-
Key words:
- wind power ramp /
- wind power /
- forecasting skill score /
- synoptic analysis
-
图 10 2023年1月10日16:00（a）、10日20:00（b）、11日16:00（c）、11日20:00（d）地面气压场（黑实线，单位：hPa）；2023年1月10日16:00（e）、10日20:00（f）、11日16:00（g）、11日20:00（h）850 hPa等压面位势高度场
（蓝实线，单位：gpm，下同）及风场（风矢，单位：m·s-1，下同）；2023年1月10日16:00（i）、10日20:00（j）、11日16:00（k）、11日20:00（l）700 hPa位势高度场及风场
红色三角形表示山西省，黑色箭头表示高压移动方向。表 2 8种场景爬坡事件的预报技能得分范围
预测值 观测值 上升爬坡 空 下降爬坡 上升爬坡 1.0~0 0 -1.0~0 空 0 — 0.0 下降爬坡 -1.0~0 0 1.0~0
下载: 导出CSV
-
[1] BANAKAR H, LUO C L, OOI B T. Impacts of wind power minute-to-minute variations on power system operation[J]. IEEE Trans Power Syst, 2008, 23(1): 150-160. [2] NAVID N, ROSENWALD G. Market solutions for managing ramp flexibility with high penetr ation of renewable resource[J]. IEEE Trans Sustain Energy, 2012, 3(4): 784-790. [3] SMITH J C, MILLIGAN M R, DEMEO E A, et al. Utility wind integration and operating impact state of the art[J]. IEEE Trans Power Syst, 2007, 22(3): 900-908. [4] DJALALOVA I, BIANCO L, AKISH E, et al. Ramp events validation during the second Wind Forecast Improvement Project (WFIP2) using the Ramp Tool and Metric (RT&M)[J]. Wea Forecast, 2020, 35(6): 2 407-2 421. [5] FRANCIS N. Predicting sudden changes in wind power generation[J]. North American Wind Power, 2008, 5(9): 58-60. [6] BOSSAVY A, GIRARD R, KARINIOTAKIS G. Forecasting ramps of wind power production with numerical weather prediction ensembles [J]. Wind Energy, 2013, 16(1): 51-63. [7] 陈浩, 何晓凤. 基于数值模式的月尺度近地层气象要素预报技术研究[J]. 热带气象学报, 2017, 33(1): 74-83. [8] 李文泽. 基于深度学习的风电爬坡识别及短期功率预测技术研究[D]. 武汉: 华中科技大学, 2021. [9] 祝赢, 柳艳香, 程兴宏, 等. 线性滚动极值处理方法对数值模拟风速的订正研究[J]. 热带气象学报, 2013, 29(4): 681-686. [10] HAN L, QIAO Y, LI M J, et al. Wind power ramp event forecasting based on feature extraction and deep Learning[J]. Energies, 2020, 13 (23): 6 448-6 468. [11] JIN C X, YANY Y, HAN C, et al. Evaluation of forecasted wind speed at turbine hub height and wind ramps by five NWP models with observations from 262 wind farms over China[J]. Meteorol Appl, 2024, 31(6): e70007. [12] 赵文婧, 李照荣, 王小勇, 等. 相似误差订正方法在风电短期风速预报中的应用研究[J]. 热带气象学报, 2021, 37(1): 73-81. [13] ZAREIPOUR H, HUANG D, ROSEHART W. Wind power ramp events classification and forecasting: A data mining approach[C]. //2011 IEEE Power and Energy Society General Meeting, 2011. [14] 崔明建, 孙元章, 柯德平, 等. 考虑电网侧频率偏差的风电功率爬坡事件预测方法[J]. 电力系统自动化, 2014, 38(5): 8-13. [15] PICHAULT M, VINCENT C, SKIDMORE G, et al. Characterisation of intra-hourly wind power ramps at the wind farm scale and associated processes[J]. Wind Energy Science, 2021, 6(1): 131-147. [16] STEINER A, KÖHlER C, METZINGER I, et al. Critical weather situations for renewable energies-Part A: Cyclone detection for wind power[J]. Renewable Energy, 2017, 101: 41-50. [17] 杨茂, 于欣楠. 考虑风电场功率爬坡的超短期组合预测[J]. 东北电力大学学报, 2022, 42(1): 63-70. [18] OKADA M, YAMAGUCHI K, KODAMA R, et al. Development of a wind power ramp forecasting system via meteorological pattern analysis[J]. Wind Energy, 2022, 25(11): 1 900-1 916. [19] 赵原松. 华北地区风电发展及润滑需求分析[J]. 石油商技, 2023, 41(6): 62-66. [20] 任爱平, 李旭霞, 胡迎迎. 山西电网风电出力特性及消纳形势分析[J]. 山西电力, 2016(3): 41-44. [21] 赵耀华, 白晓, 王琼. 山西省风电现状和未来发展探讨[J]. 山西电力, 2021(5): 10-14. [22] 王皑, 安立进. 山西省风电发展存在的问题及相关建议[J]. 山西电力, 2011(6): 9-11. [23] 刘洋, 杨亦. 电力现货市场提速, 新能源电力入市迎来"大考"[J]. 记者观察, 2024(4): 84-87. [24] 山西省能源局, 国家能源局山西监管办公室. 电力市场规则体系(V14.0)[EB/OL]. [2024-1-24]. http://nyj.shanxi.gov.cn/zfxxgk/fdzdgknr/gfxwj/202403/P020240311423237367586.pdf .[25] 张人文, 范绍佳, 李颖敏. 2008年秋季从化山谷风观测研究[J]. 热带气象学报, 2012, 28(1): 134-139. [26] ZACK J W, YOUNG S, NATENBERG E J. Evaluation of wind ramp forecasts from an initial version of a rapid update dynamical-statistical ramp prediction system[C]. //Second Conference on Weather, Climate, and the New Energy Economy, 2011. [27] FERREIRA C, GAMA J, MATIAS L, et al. A survey on wind power ramp forecasting[R]. Argonne National Laboratory, 2011. [28] GREAVES B, COLLINS J, PARKES J, et al. Temporal forecast uncertainty for ramp events[J]. Wind Energy, 2009, 33(4): 309-320. [29] CUTLER N, KAY M, NIELSEN T S, et al. Detecting, categorizing and forecasting large ramps in wind farm power output using meteorological observations and WPPT. Wind Energy, 2007, 5(10): 453-470. [30] BOSSAVY A, GIRARD R, KARINIOTAKIS G. Forecasting uncertainty related to ramps of wind power production[C]. //European Wind Energy Conference & Exhibition, 2010. [31] ZACK J W, YOUNG S, NOCERA J, et al. 2010: Development and testing of an innovative short-term large wind ramp forecasting system [C]. //European Wind Energy Conference & Exhibition, 2010. [32] KAMATH C. Understanding wind ramp events through analysis of historical data[C]. //Transmission and Distribution Conference and Exposition, 2010. [33] BIANCO L, DJALALOVA I V, WILCZAK J M, et al. A wind energy ramp tool and metric for measuring the skill of numerical weather prediction models[J]. Wea Forecasting, 2016, 31(4): 1 137-1 156. [34] 戚永志. 大规模风电爬坡有限度控制研究[D]. 济南: 山东大学, 2016. [35] YU R, LI J, CHEN H. Diurnal variation of surface wind over central eastern China[J]. Climate Dyn, 2009, 33(7): 1 089-1 097. [36] HONG, SEONG-HO H, LKHAMJAV J, et al. Spatiotemporal variations of 100 m wind in Mongolia and implications for wind energy resources[J]. Int J Climatol, 2023, 43(7). [37] BAAS P, BOSVELD F C, BALTINK H K, et al. A Climatology of Nocturnal Low-Level Jets at Cabauw[J]. J Appl Meteorol Climatol, 2010, 48(8): 1 627-1 642. [38] 郝寿昌. 山西省天气预报技术手册[M]. 北京: 气象出版社, 2016. [39] WILCZAK J M, OLSON J B, DJALALOVA I V, et al. Data assimilation impact of in situ and remote sensing meteorological observations on wind power forecasts during the first Wind Forecast Improvement Project (WFIP)[J]. Wind Energy, 2019, 22(7): 932-944. -
